ProCut AF

PRODUCTS

PROCUT AF

Alcohol-free tube cutting with automated precision. The first machine to measure and cut tacky medical tubing without alcohol, water, or compressed air.

The ProCut AF tube cutter advances the technology for processing medical tubing in your cleanroom. It is the first machine to automatically measure and cut tacky tubing without the need for alcohol, water, or compressed air. Just plug it into a standard outlet and start cutting.

Key Features

WHAT MAKES PROCUT AF DIFFERENT

Programmable

The user-friendly interface lets you choose cut length, quantity, and cutting mode, then guides you through setup with simple instructions. All process parameters are fully customizable, allowing precise control over a wide range of tubing materials. Configurable recipes provide a simple and repeatable setup for consistent results.

Accurate

Our unique wheel design provides four points of contact per wheel pair. Up to five pairs of wheels can be used for redundant contact, resulting in no-slip feeding without machine adjustments. This precise guiding system delivers unmatched repeatability and accuracy.

Reliable

Our patent-pending bushings enable frictionless feeding and consistent cutting, as programmed in your recipe. The machine handles PVC, C-flex, Nylon, TPE, and silicone with the same reliable results. Each blade delivers up to 250,000 accurate, particulate-free cuts.

No Tools Needed

ProCut AF handles 17 standard diameters ranging from .1875 inches (4.76 mm) to 1.5 inches (38 mm), with custom sizes available on request. Changeover takes under five minutes and requires no tools.

Technical Specifications

THE FULL SPEC SHEET

Spec callouts:

Tubing Compatibility: PVC, C-flex, Nylon, TPE, silicone
Standard Diameters:17 sizes from .1875" (4.76 mm) to 1.5" (38 mm)
Custom Diameters:Available on request
Cutting Method:Cutting Method:
Blade Life:Up to 250,000 particulate-free cuts
Changeover:Under 5 minutes, no tools required
Interface:Programmable HMI with configurable recipes
Power:Standard outlet connection

Built For

MEDICAL TUBING PRODUCTION, REFINED

ProCut AF is engineered for medical device and life science manufacturers producing tubing in cleanroom environments. It is the right machine when consistency matters more than anything else: when blade-to-blade variation, operator intervention, or the use of alcohol or liquids in your process are not options. ProCut AF eliminates all three.

Ideal for:

Medical tubing production in cleanroom environments
Manufacturers cutting tacky tubing that standard cutters cannot handle
Operations with multiple tubing materials on the same line
Production environments that cannot introduce alcohol, water, or compressed air
